HDMI & IR Extender Over CAT5e CAT6 70m - HDC6IRLv2

HDMI & IR Extender Over CAT5e CAT6 70m - HDC6IRLv2

Extends the HDMI signal between the transmitter and receiver up to 70 meters over a single CAT6 or CAT5e cable.

• Sends 4K or 2K HDCP 1.4 Video at up to 30Hz, as far as 70 metres

• Electronic Display IDentification sync's Output Resolution to Monitor

• Embedded Multi-Channel Audio and Embedded Infra Red Remote Control Extender

BENEFITS

• Sends 4K or 2K 30Hz Video as far as 70m, with Embedded Multi-Channel Audio and IR extension.

  The maximum transmission distance via a single CAT6/5E cable is as follows:

• CAT6:   230ft/70 Metres for 1080p, 13ft/40 Metres for 4K30

• CAT5E: 197ft/60 Metres for 1080p, 115ft/35 Metres for 4K30

• Transmitter Loop Out provides an additional HDMI out that permits cascading

• Power over Cable runs the Receiver & Transmitter from just 1 power supply

• Automatic CAT6 or CAT5e cable length equalization, no switches to set

• EDID used to select optimum output display or monitor resolution

• IR repeater included can be bi-directional (optional)

• HDMI 1.4, HDCP 1.4 and DVI 1.0 Compliant



PACKAGE CONTENTS

• 1x HDMI Transmitter

• 1x HDMI Receiver

• 1x IR Blaster (sender) 1.5 metre cable

• 1x IR Target (receiver) 1.5 metre cable

• 1x 12V 1 Amp DC Power Adapter

• 1x User Manual
